MR4PMUHV Electronic Temperature/Defrost Control with Relay Pack Product/Technical Bulletin 13
Technical Specifications
Product
MR4PMUHV-12C Temperature/Defrost Control
Relay Electrical Ratings
See Tables 7-9.
Frequency
60 Hz
Power Requirements
120/240 VAC ±10%
Maximum Power
Consumption
10 VA @120/240 VAC
Accuracy
±1.8F° (±1C°)
Sensor Input Range
-40 to 158°F (-40 to 70°C)
A99B Sensor Cable
6-1/2 ft (2 m)
Ambient Operating
Conditions
MR4PMUHV-12C*: 14 to 111°F (-10 to 44°C); 0 to 95 % RH (noncondensing)
MR4PM12C-12C: 14 to 140°F (-10 to 60°C); 0 to 95 % RH (noncondensing)
RP4MRUHV-1C*: -40 to 111°F (-40 to 44°C); 0 to 95 % RH (noncondensing)
Ambient Storage
Conditions
MR4PMUHV-12C: -22 to 176°F (-30 to 80°C) 0 to 95 % RH (noncondensing)
MR4PM12C-12C: -22 to 176°F (-30 to 80°C) 0 to 95 % RH (noncondensing)
RP4MRUHV-1C: -40 to 185°F (-40 to 85°C) 0 to 95 % RH (noncondensing)
Dimensions (H x W x D)
See Figures 3-5.
Agency Listings
UL Listed (US), File SA516, CCN SDFY
UL Listed (Canada), File SA516, CCN SDFY7
Emissions Compliance
FCC (US)
DOC (Canada)
Shipping Weight
See Table 6.
* See Relay Electrical Ratings.
The performance specifications are nominal and conform to acceptable industry standards. For application at conditions beyond these
specifications, consult Johnson Controls/Penn Application Engineering at 1-800-275-5676. Johnson Controls, Inc. shall not be liable for
damages resulting from misapplication or misuse of its products.
Controls Group
507 E. Michigan Street
P.O. Box 423 Printed in U.S.A.
Milwaukee, WI 53201 www.johnsoncontrols.com
