Ordering information
The following tables list the product code numbers for all available NAE35 and NAE45 network
engines based on model. If you receive an NAE35 or NAE45 engine from the factory that is imaged
with Release 9.0, you can field-upgrade the engine to Release 9.0.7 if the upgrade is supported, but
modem and pager functionality is lost. For details, refer to the following table.
Note: Some NAE models are also available in a Buy American version (add a G after the
product code number). For the European version, add an E after the product code number. For
repair parts, add -703 after the product code number.
Table 9: NAE35 ordering information
Product Code
Number
Release
Supported
Description
MS-NAE35xx-
xxx (Base
Features of
Each NAE35)
N/A NAE35 Network Automation Engines: Requires a 24 VAC power
supply. Each model includes one RS-232-C serial port, one
USB serial port, one Ethernet port, and an MS-BAT1020-0 Data
Protection Battery.
MS-NAE3510-2 9.0.7 Supports one N2 or BACnet MS/TP (RS-485) trunk; includes an
additional RS-232-C serial port; supports a maximum of 50 devices
on the N2 or BACnet MS/TP trunk.
MS-NAE3511-2
9.0.7
1
Supports one N2 or BACnet MS/TP (RS-485) trunk; includes an
internal modem; supports a maximum of 50 devices on the N2 or
BACnet MS/TP trunk.
Note: Modem and pager functions are no longer available if
this engine is updated with Metasys Release 9.0.7 or later.
MS-NAE3514-2 9.0.7 Supports one N2 or BACnet MS/TP (RS-485) trunk; features Basic
Access support; includes an additional RS-232-C serial port;
supports a maximum of 50 devices on the N2 or BACnet MS/TP
trunk.
MS-NAE3515-2
9.0.7
1
Supports one N2 or BACnet MS/TP (RS-485) trunk; features Basic
Access support; includes an internal modem; supports a maximum
of 50 devices on the N2 or BACnet MS/TP trunk.
Note: Modem and pager functions are no longer available if
this engine is updated with Metasys Release 9.0.7 or later.
MS-NAE3520-2 9.0 Supports one LonWorks trunk, includes an additional RS-232-C
serial port. Supports a maximum of 64 devices on the LonWorks
trunk.
MS-NAE3524-2 9.0 Supports one LonWorks trunk, features Basic Access support, and
includes an additional RS-232-C serial port. Supports a maximum
of 64 devices on the LonWorks trunk.
1 This model is imaged with Release 9.0 at the factory but can be field-upgraded to Release 9.0.7.
23NAE35/NAE45 Installation Guide
