Table 10: NAE45 ordering information
Product Code
Number
Release
Supported
Description
MS-NAE45xx-
xxx (Base
features of each
NAE45)
N/A NAE45 Network Automation Engines: Requires a 24 VAC power
supply. Each model includes one RS-232-C serial port, one
USB serial port, one Ethernet port, and an MS-BAT1020-0 Data
Protection Battery.
MS-NAE4510-2 9.0.7 Supports one N2 or BACnet MS/TP (RS-485) trunk; includes an
additional RS-232-C serial port; supports a maximum of 100
devices on the N2 or BACnet MS/TP trunk.
MS-NAE4511-2
9.0.7
1
Supports one N2 or BACnet MS/TP (RS-485) trunk; includes an
internal modem; supports a maximum of 100 devices on the N2 or
BACnet MS/TP trunk.
Note: Modem and pager functions are no longer available if
this engine is updated with Metasys Release 9.0.7 or later.
MS-NAE4520-2 9.0 Supports one LonWorks trunk, includes an additional RS-232-C
serial port; supports a maximum of 127 devices on the LonWorks
trunk.
MS-NAE4521-2 9.0 Supports one LonWorks trunk, includes an internal modem;
supports a maximum of 127 devices on the LonWorks trunk.
MS-NAE451L-2 9.0.7 Supports one BACnet MS/TP (RS-485) trunk; supports a maximum
of 100 BACnet MS/TP devices on the trunk. (N2 Bus field trunk
is not supported.) This model is currently available only in
select regions. For details, refer to the ADS-Lite Product Bulletins
(LIT-12011690 and LIT-12011694).
Note: The MS-NAE451L-2 requires an MS-ADSLA5U-0 Site
Director.
1 This model is imaged with Release 9.0 at the factory but can be field-upgraded to Release 9.0.7.
Table 11: NAE35/45 accessories ordering information
Product Code
Number
Description
MS-BAT1020-0 Replacement data protection battery for NAE35, NIE39, NAE45, NIE45, NIE49,
NCE25, or NIE29. Rechargeable NiMH 3.6 VDC, 500 mAh battery with a typical
life of 5 to 7 years at 21°C (70°F) (Higher operating temperatures reduce
battery life.)
AS-XFR050-0 Power transformer (Class 2, 24 VAC, 50 VA maximum output), no enclosure
NAE35/NAE45 Installation Guide24
