Accessories
Table 16: NIE29 Accessories Ordering Information
DescriptionProduct Code Number
Replacement data protection battery for NIE39/49 and NIE29: Rechargeable NiMH 3.6 VDC, 500
mAh battery with a typical life of 5 to 7 years at 21°C (70°F) (Higher operating temperatures reduce
battery life.)
MS-BAT1020-0
Transformer, 120/208/240 VAC Primary to 24 VAC Secondary, 40 VA, Foot Mount, 8 in. Primary
Leads and Secondary Screw Terminals, Class 2
Y65T31-0
Power transformer (Class 2, 24 VAC, 50 VA maximum output), no enclosureAS-XFR050-0
Optional Local Controller Display (Only for NIE29 models without an integral display. See .)MS-DIS1710-0
Wireless Commissioning Converter, with Bluetooth® TechnologyMS-BTCVT-1
Modbus RS232-to-RS485 converter, 230 VAC
IU-9100-8401 (Europe)
1
Modbus RS232-to-RS485 converter, 24 VAC
IU-9100-8404 (Europe)
1
or
BM485-CIP (North
America)
2
RS232-to-M-Bus level converter for up to 6 unit loads; 24 VAC/VDC
SIS-MBUSSCSL-0E
1
RS232-to-M-Bus level converter for up to 100 unit loads; 24 VAC/VDC
SIS-MBUSSCLL-0E
1
RS232-to-M-Bus level repeater for up to 100 unit loads; 24 VAC/VDC
SIS-MBUSRPLL-0E
1
RS232-to-M-Bus level repeater for up to 100 unit loads; 230 VAC
SIS-MBUSRPLH-0E
1
IP-to-M-Bus level converter for up to 100 unit loads; 24 VAC/VDC
SIS-MBUSNCLL-0E
1
IP-to-M-Bus level converter for up to 100 unit loads; 230 VAC
SIS-MBUSNCLH-0E
1
Optional connection cable SUB-D to RJ-12 for use with SIS-MBUSSCLL-0E
INT-DX-KAB01
1
KNX IP interface module to connect KNX line via Ethernet to an NIEx9
SIS-KNXNIXL-0E
1
KNX IP router to connect KNX line via Ethernet to an NIEx9, including line or area coupler functionality
SIS-KNXNRXL-0E
1
1 European market: order this accessory in AOMS from the Essen Distribution Center.
2 North American market: order this accessory from duTec Baudmaster™ (http://www.interfaceconverter.com) or
1-800-248-1632, specify vendor #290904.
Modbus Integrations require one or more vendor model definition (VMD) tables for specific third-party equipment.
You can purchase tables from your regional System Integration Services (SIS) office, or you can create the tables
with the VMD Generator Express (VGE) tool. The VGE tool requires certification and licensing for its use. To obtain
a license, attend the training listed in Table 17.
Table 17: VGE Tool Training Registration
DescriptionProduct Code Number
The VGE Tool Software Training (North America)
The VGE tool is required to generate custom Modbus mapping tables for the NIE.
C-10077
The VGE Tool Software Training (Europe and Asia)
The VGE tool is required to generate custom Modbus mapping tables for the NIE.
PTK-CONT-25
