P—P70, P72, and P170 Controls for Dual Pressure Applications Product/Technical Bulletin 11
E
lectrical Ratings
Table 3: SPST Electrical Ratings (P70L, M, and N, and P170L, M, and N Types)
Standard Single-Phase Ratings Hermetic Compressor
Single-Phase Ratings
120 VAC 208 VAC 240 VAC 208/240 VAC
Motor Horsepower
1.5 3 3 --
Motor Full Load Amperes
20 18.7 17 20
Motor Locked Rotor Amperes
120 112.2 102 120
Non-Inductive Amperes
22 22 22 --
Pilot Duty
125 VA at 120 to 600VAC; 57.5 VA at 120 to 300 VDC
Table 4: 4-wire 2-circuit Electrical Ratings (P70P, Q, and R Types)
Standard Single-Phase Ratings
Line-M2 (Main Contacts) Line-M1 (Auxiliary Contacts)
120 VAC 208 VAC 240 VAC 277 VAC 120 VAC 208 VAC 240 VAC 277 VAC
Motor Full Load
Amperes
16.0 9.2 8.0 -- 6.0 3.3 3.0 --
Motor Locked Rotor
Amperes
96.0 55.2 48.0 -- 36.0 19.8 18.0 --
Non-Inductive
Amperes
16.0 9.2 8.0 7.2 6.0 6.0 6.0 6.0
Pilot Duty (for both
sets of contacts)
125 VA at 24 to 600 VAC; 57.5 VA at 120 to 300 VDC
Table 5: SPDT Electrical Ratings (P70S and P170S Types)
Standard Single-Phase Ratings
120 VAC 208 VAC 240 VAC 277 VAC
Motor Full Load Ampere
16.0 9.2 8.0 7.0
Motor Locked Rotor Ampere
96.0 55.2 48.0 42.0
Non-Inductive Ampere
16.0 9.2 8.0 7.0
Pilot Duty
125 VA at 24 VAC, 720 VA at 120 to 277 VAC
Table 6: DPST Electrical Ratings (P72L, M, and N Types)
Standard Ratings Hermetic
Compressor Ratings
120 VAC
208 VAC
240 VAC
208 VAC
220 VAC
208 VAC
240 VAC
Motor Horsepower
2335 5 -- --
Motor Full Load Amperes
24 18.7 17 15.9 15 24 24
Motor Locked Rotor Amperes
144 112.2 102 95.4 90 144 144
AC Non-Inductive Amperes
24 24 24 24 24 -- --
DC Non-Inductive Amperes
3 0.5 0.5 0.5 0.5 -- --
Pilot Duty
125 VA at 120 to 600VAC; 57.5 VA at 120 to 300 VDC
