Johnson Controls PENN P70 Series User Manual

12 P—P70, P72, and P170 Controls for Dual Pressure Applications Product/Technical Bulletin
S
pecifications
Product P70, P72, and P170 Dual Pressure Controls
Switch Action P70, P170: SPST or 4-wire, 2-circuit
P70S, P170S: Two SPDT
PENN switches
P72: DPST
Pressure Connection
Call Application Engineering
at (414) 524-5535 for
pressure connection styles
available
P70, P72 Standard Models
various connections available
(Styles 5, 13, 15, 34, 37)
See Figure 13.
P170 Standard
Models
1/4 in. male flare hose
connection (Style 5)
See Figure 13.
P70LA-2, P70MA-2 Ammonia
Compatible Models
1/4 in. female NPT connection
(Style 15) See Figure 13.
Maximum Overpressure Low Side All-Range: 325 psig (2241 kPa)
Low Side MICRO-SET: 525 psig (3620 kPa)
High Side (All-Range and MICRO-SET): 525 psig (3620 kPa)
Maximum Working
Pressure
Low Side All-Range: 100 psig (552 kPa)
Low Side MICRO-SET: 80 psig (690 kPa)
High Side (All-Range and MICRO-SET): 500 psig (3447 kPa)
Ambient Conditions -40 to 104°F (-40 to 40°C)
Case and Cover NEMA 1 Enclosures: Galvanized steel case, plated and painted steel cover
NEMA 3R Enclosures: Plated and painted steel case and cover
Dimensions (H x W x D) NEMA 1 Enclosure: 3-1/4 x 5-11/16 x 2-1/16 in. (83 x 144 x 53 mm)
NEMA 3R Enclosure: 4-13/16 x 5-13/16 x 3-3/8 in. (122 x 148 x 86 mm)
Approximate
Shipping Weight
NEMA 1 Individual: 3.5 lb (1.6 kg); Bulk pack (multiples of 25 controls): 75.5 lb (34.2 kg)
NEMA 3R Individual: 4.7 lb (2.1 kg); Bulk pack (multiples of 25 controls): 116.5 lb (52.9 kg)
Agency Listings
For information on specific items, contact the Refrigeration Application Engineering Group
at (414) 524-5535.
Accessories 271-51 Universal Mounting Bracket (supplied with standard controls)
The performance specifications are nominal and conform to acceptable industry standards. For application at conditions beyond these
specifications, contact Refrigeration Application Engineering at (414) 524-5535. Johnson Controls, Inc. shall not be liable for damages
resulting from misapplication or misuse of its products.
Controls Group www.johnsoncontrols.com
507 E. Michigan Street FAN 125
P.O. Box 423 Master Catalog
Milwaukee, WI 53201 Printed in U.S.A.
