VFD68 Variable Frequency Drives Product Bulletin6
Selection Charts
Table 5: 230 VAC ±10% Production Models
Product Code Number Description
VFD68BBB-2C VFD68 Drive; 0.1 kw (1/8 hp); 128 x 68 x 81 mm (5 x 2-11/16 x 3-3/16 in.)
VFD68BCB-2C VFD68 Drive; 0.2 kw (1/4 hp); 128 x 68 x 81 mm (5 x 2-11/16 x 3-3/16 in.)
VFD68BDC-2C VFD68 Drive; 0.4 kw (1/2 hp); 128 x 68 x 113 mm (5 x 2-11/16 x 4-7/16 in.)
VFD68BFD-2C VFD68 Drive; 0.75 kw (1 hp); 128 x 68 x 133 mm (5 x 2-11/16 x 5-1/4 in.)
VFD68BGG-2C VFD68 Drive; 0.5 kw (2 hp); 128 x 108 x 136 mm (5 x 4-1/4 x 5-5/16 in.)
VFD68BHG-2C VFD68 Drive; 2.2 kw (3 hp); 128 x 108 x 136 mm (5 x 4-1/4 x 5-5/16 in.)
VFD68BJK-2C VFD68 Drive; 3.7 kw (5 hp); 128 x 170 x 142 mm (5 x 6-11/16 x 5-5/8 in.)
VFD68BKL-2C VFD68 Drive; 5.5 kw (7-1/2 hp); 150 x 220 x 155 mm (5-15/16 x 8-11/16 x 6-1/8 in.)
VFD68BLL-2C VFD68 Drive; 7.5 kw (10 hp); 150 x 220 x 155 mm (5-15/16 x 8-11/16 x 6-1/8 in.)
VFD68BMP-2C VFD68 Drive; 11 kw (15 hp); 260 x 220 x 190 (10-1/4 x 8-11/16 x 7-1/2)
VFD68BNP-2C VFD68 Drive; 15 kw (20 hp); 260 x 220 x 190 (10-1/4 x 8-11/16 x 7-1/2)
Table 6: 460 VAC ±10% Production Models
Product Code Number Description
VFD68CDF-2C VFD68 Drive; 0.4 kw (1/2 hp); 128 x 108 x 130 mm (5 x 4-1/4 x 5-1/8 in.)
VFD68CFF-2C VFD68 Drive; 0.75 kw (1 hp); 128 x 108 x 130 mm (5 x 4-1/4 x 5-1/8 in.)
VFD68CGG-2C VFD68 Drive; 1.5 kw (2 hp); 128 x 108 x 136 mm (5 x 4-1/4 x 5-5/16 in.)
VFD68CHH-2C VFD68 Drive; 2.2 kw (3 hp); 128 x 108 x 156 mm (5 x 4-1/4 x 6-1/8 in.)
VFD68CJJ-2C VFD68 Drive; 3.7 kw (5 hp); 128 x 108 x 166 mm (5 x 4-1/4 x 6-1/2 in.)
VFD68CKL-2C VFD68 Drive; 5.5 kw (7-1/2 hp); 150 x 220 x 155 mm (5-15/16 x 8-11/16 x 6-1/8 in.)
VFD68CLL-2C VFD68 Drive; 7.5 kw (10 hp); 150 x 220 x 155 mm (5-15/16 x 8-11/16 x 6-1/8 in.)
VFD68CMP-2C VFD68 Drive; 11 kw (15 hp); 260 x 220 x 190 (10-1/4 x 8-11/16 x 7-1/2)
VFD68CNP-2C VFD68 Drive; 15 kw (20 hp); 260 x 220 x 190 (10-1/4 x 8-11/16 x 7-1/2)
Table 7: 575 VAC +5/-10% Production Models
Product Code Number Description
VFD68DFM-2C VFD68 Drive; 0.75 kw (1 hp); 150 x 140 x 136 mm (5-15/16 x 5-1/2 x 5-5/16 in.)
VFD68DGM-2C VFD68 Drive;1.5 kw (2 hp); 150 x 140 x 136 mm (5-15/16 x 5-1/2 x 5-5/16 in.)
VFD68DHM-2C VFD68 Drive; 2.2 kw (3 hp); 150 x 140 x 136 mm (5-15/16 x 5-1/2 x 5-5/16 in.)
VFD68DJN-2C VFD68 Drive; 3.7 kw (5 hp); 150 x 220 x 148 mm (5-15/16 x 8-11/16 x 5-13/16 in.)
VFD68DKN-2C VFD68 Drive; 5.5 kw (7-1/2 hp); 150 x 220 x 148 mm (5-15/16 x 8-11/16 x 5-13/16 in.)
VFD68DLN-2C VFD68 Drive; 7.5 kw (10 hp); 150 x 220 x 148 mm (5-15/16 x 8-11/16 x 5-13/16 in.)
