Johnson Controls PENN VFD68 Product Bulletin

VFD68 Variable Frequency Drives Product Bulletin8
Technical Specifications
VFD68 Variable Frequency Drive
Input Power Voltage/Frequency 230 VAC, 50 HZ (208/230 VAC, 60 Hz);
400 VAC, 50 Hz (460 VAC, 60 Hz);
575 VAC, 50 Hz;
Continuous Duty
Output Voltage/Frequency 230 VAC, 50 HZ (208/230 VAC, 60 Hz);
400 VAC, 50 Hz (460 VAC, 60 Hz);
575 VAC, 50 Hz;
Continuous Duty
Input Devices Johnson Controls/PENN® P499 Electronic Pressure Transducers
PWM Carrier Frequency Adjustable 0.7 to 15 kHz
Motor Requirements Three-phase NEMA Design B motors required; Inverter-rated motors recommended
Overload Capacity 150% of ampere rating for 1 minute
Start/Stop Use STF input to start or stop the motor
Ambient Conditions Storage: -40 to 65ºC (-40 to 149ºF), 0 to 95% RH noncondensing
Operating: -40 to 50ºC (-40 to 122ºF), 0 to 95% RH noncondensing
Altitude: 1,000 m (3,300 ft) Maximum without derating
Enclosures UL Type 1 (NEMA) Fan Cooled
(230 VAC 1 hp and lower models do not have a fan)
Maximum High Voltage Wire
Length
Up to 100 m (328 ft) between the VFD68 drive and the motor (using the appropriate wire
gauge)
Compliance North America: cULus Listed, UL 508C, CSA-C22.2 No. 14, File E244421;
Industry Canada (IC) Compliant to Canadian ICES-003, Class B limits
Europe: CE Mark - Johnson Controls, Inc. declares that this product is in compliance with
the essential requirements and other relevant provisions of the EMC Directive and the
Low Voltage Directive.
Australia: Regulatory Compliance Mark (RCM)
Dimensions (H x W x D) Minimum: 128 x 68 x 81 mm (5 x 2-11/16 x 3-3/16 in.)
Maximum: 260 x 220 x 190 mm (10-1/4 x 8-11/16 x 7-1/2 in.)
Shipping Weight 230 VAC ±10% Production Models:
VFD68BBB, VFD68BCB: 0.5 kg (1.1 lb)
VFD68BDC: 0.8 kg (1.8 lb)
VFD68BFD: 1.0 kg (2.2 lb)
VFD68BGG, VFD68BHG: 1.4 kg (3.1 lb)
VFD68BJK: 1.8 kg (4.0 lb)
VFD68BKL, VFD68BLL: 3.6 kg (8.0 lb)
VFD68BMP, VFD68BNP: 6.5 kg (14.3 lb)
460 VAC ±10% Production Models:
VFD68CDF, VFD68CFF: 1.3 kg (2.9 lb)
VFD68CGG: 1.4 kg (3.1 lb)
VFD68CHH, VFD68CJJ: 1.5 kg (3.3 lb)
VFD68CKL, VFD68CLL: 3.3 kg (7.3 lb)
VFD68CMP, VFD68CNP: 6.5 kg (14.3 lb)
575 VAC +5/-10% Production Models:
VFD68DFM: 1.8 kg (3.96 lb)
VFD68DGM, VFD68DHM: 2.0 kg (4.41 lb)
VFD68DJN, VFD68DKN, VFD68DLN: 3.8 kg (8.38 lb)
