Table 8: Transducer Kits and Wire Harnesses
Product Code
Number
Description Accessory Information
P499RAPS100K
P499RCPS100K
Electronic Pressure Transducer (-10 to 100 psis
[sealed for wet and freeze/thaw applications]
Range) and WHA-PKD3-200C Wire Harness
• Product code numbers ending in K are P499 kit
models that include a P499 Pressure
Transducer model and a WHA-PKD3-200C
(2 m [6-1/2 ft ]) Wire Harness. To order a single
P499 Pressure Transducer model (without a
WHA-PKD3-200C Wire Harness), replace the
K with a C at the end of the P499 product code
number.
• P499RxP type models are 0.5 to 4.5 VDC
ratiometric pressure transducers with Packard
style electrical connections.
• P499RAP type models have a 1/8 in. 27 NPT
external thread (Style 49) pressure connection.
• P499RCP type models have a 1/4 in. SAE 45°
flare internal thread (7/16-20 UNF) with
depressor (Style 47) pressure connection.
• Refer to the P499 Series Electronic Pressure
Transducers Product/Technical Bulletin
(LIT-12011190) for more information on
P499 Pressure Transducer models and the
associated wire harnesses.
P499RAPS102K
P499RCPS102K
Electronic Pressure Transducer (0 to 200 psis
[sealed for wet and freeze/thaw applications]
Range) and WHA-PKD3-200C Wire Harness
P499RAP-101K
P499RCP-101K
Electronic Pressure Transducer (0 to 100 psig
Range) and WHA-PKD3-200C Wire Harness
P499RAP-102C Electronic Pressure Transducer (0 to 200 psig
Range)
P499RAP-105K
P499RCP-105K
Electronic Pressure Transducer (0 to 500 psig
Range) and WHA-PKD3-200C Wire Harness
P499RAP-107K
P499RCP-107K
Electronic Pressure Transducer (0 to 750 psig
Range) and WHA-PKD3-200C Wire Harness
WHA-PKD3-200C Wire Harness, 2 m (6-1/2 ft)
WHA-PKD3-400C Wire Harness, 4 m (13 ft)
WHA-PKD3-400C Wire Harness, 6 m (19-5/8 ft)
