TEC3000 Series Wireless Proportional Fan Coil and Individual Zone Thermostat Controllers with Dehumidification
Capability Installation Instructions
37
Network Setup FC Comm Mode Wireless Field Bus —
BACnet Instance ID* 1 0 to 4,914,302
* BACnet/MSTP communication mode
BACnet Device Address* 4 4 to 127
* BACnet/MSTP communication mode
BACnet Encoding Type
BACnet/MSTP Communication Mode
ISO 10646
(UCS-2)
ISO 10646 (UCS-2), ANSI X3.4
(US-ASCII)
Pan ID 65535 0 to 127
Equipment Setup General
Unit Type 4-Pipe 2-Pipe, 4-Pipe, VAV
Valve Open Voltage 10 VDC 0 to 10 VDC
Valve Closed Voltage 0 VDC 0 to 10 VDC
Unoccupied Off Delay 10 minutes 0 to 10 minutes
Supply Fan
Supply Fan Type* Single Speed Single Speed, Multi-speed, Variable
Speed
* Fan coil units only
Start Voltage* 2 VDC 0 to 10 VDC
* Fan coil units only, variable speed fan
Full Speed Voltage* 10 VDC 0 to 10 VDC, proportional
* Fan coil units only, variable speed fan
Min Command* 20% 0 to 100%
* Fan coil units only, variable speed fan
Med Fan Speed On Cmd* 33% 0 to 100%
* Fan coil units only, multi-speed fan
High Fan Speed On Cmd* 66% 0 to 100%
* Fan coil units only, multi-speed fan
Reheat
Reheat Installed No Yes (True) or No (False)
Reheat Min Damper Position* 20% 0 to 100%
* VAV units with reheat installed
Reheat Fan Required* No Yes or No
* Fan coil units with reheat installed
Reheat Min On Time* 180 seconds 0 to 360 second
* Reheat installed
Reheat Min Off Time* 180 seconds 0 to 360 seconds
* Reheat installed
Changeover
Changeover Mode* Auto Auto, Cooling, or Heating
* Non 4-Pipe units
Supply Temp Type* Analog Sensor Analog Sensor, Heating NC, Cooling NC
* Changeover Mode = Auto
Changeover Setpoint* 55°F 40 to 200°F (4 to 93°C)
* Supply temp type = analog sensor
Table 10: Menus and Submenus (Part 5 of 8)
