TEC3000 Series Networked and Wireless Proportional Fan Coil and Individual Zone Thermostat Controllers with
Dehumidification Capability Installation Guide
39
Setup General Control Setup
Control Mode
Unit Enable
Fan Mode*
Max Setpoint Offset
Fan On Delay*
Fan Off Delay*
Frost Protection
Dehum Enable*
Aux Mode
Load Shed Rate Limit
Load Shed Adjust
Fan Alarm Delay
Fan Alarm Action*
Fan Alarm Reset*
Fan Runtime Limit
Fan Runtime Reset*
Supply Air Temperature Alarm Offset
Supply Air Temperature Alarm Delay*
Unocc Low Speed Fan
Inputs
BI1 Config
BI2 Config
Supply Temp Sensor*
Supply Temp Offset*
Zone Temp Sensor*
Zone Temp Offset
Humidity Offset
Reset Sensors
Zone Temp Alarm Enabled (for TEC networked models)
Zone Temp Low Limit (for TEC networked models)
Zone Temp High Limit (for TEC networked models)
Tuning
Temp Control Setup
Reset PID Tuning
Deadband*
Table 13: Menus and submenus (Part 3 of 6)
Level 1 Level 2
(LCD screen name)
