VA7800 Series Electric Valve Actuators Product Bulletin
6
Ordering Information
Contact the nearest Johnson Controls representative
and specify the desired product code number from
Table 5.
Repair Information
If a VA78x0-xxx-2 Series Electric Valve Actuator fails to
operate within specifications, replace the unit. For a
replacement actuator, contact the nearest
Johnson Controls representative.
Table 5: VA-78x0-xxx-2 Series Electric Valve Actuators
Code Number Input Signal Power
Requirements
Action on Power
Failure
Feedback Auxiliary
Switches
Nominal Stroke Time
1
(Seconds)
On/Off Floating Point Proportional 0 (2) to 10 VDC 0 (4) to 20 mA 24 VAC 50/60 Hz ± 15% 230 VAC 50/60 Hz ± 15% VA Rating Non-Spring Return Spring Return Actuator Retracted Valve Stem Full Up Spring Return Actuator Extended Valve Stem Full Down 0 (2) to 10 VDC 2 SPDT, 1A, 3A Resistive, 1/4 HP 1/2 and 3/4 in. VG7000 (5/16 in. valve stroke) 1 and 1-1/4 in. VG7000 (1/2 in. valve stroke) 1-1/2 and 2 in. VG7000 (3/4 in. valve stroke)
VA7810-ADC-2 X X --- --- X 8 X --- --- --- X 48 76 114
VA7810-AGA-2 X X --- X --- 3 X --- --- --- --- 48 76 114
VA7810-AGC-2 X X --- X --- 3 X --- --- --- X 48 76 114
VA7810-HGA-2 X X X X --- 6 X --- --- X --- 24/48 38/76 57/114
VA7810-HGC-2 X X X X --- 6 X --- --- X X 24/48 38/76 57/114
VA7820-HGA-2 X X X X --- 11 --- X --- X --- 24/48 38/76 57/114
VA7820-HGC-2 X X X X --- 11 --- X --- X X 24/48 38/76 57/114
VA7830-HGA-2 X X X X --- 11 --- --- X X --- 24/48 38/76 57/114
VA7830-HGC-2 X X X X --- 11 --- --- X X X 24/48 38/76 57/114
1. VA78x0-HGx-2 actuators have field selectable stroke speed; factory setting is the slowest speed.
Table 6: Accessories Ordering Information
Product Code Number Description
V-9999-BC1 Mounting Kit to Mount VA-715x, VA-720x, VA78xx, or VA-4233 Series Electric Actuators
to Barber Coleman® 1/2 through 1-1/4 Inch VB-9xxx Valve Bodies
V-9999-HW1 Mounting Kit to Mount VA-715x, VA-720x, VA78xx, or VA-4233 Series Electric Actuators
to Honeywell® V5011A, F, and G, 1/2 through 3 Inch Single-Seated and V5013F
Three-Way Valves
