Johnson Controls VMA1615 Installation Instructions

Table 10: VMA1615/1626/1628/1630 Controller Accessories (Order Separately)
DescriptionProduct Code Number
Cable adapter for connection to 8-pin TE-6700 Series sensorsAS-CBLTSTAT-0
Replacement Barbed Fitting for use on VMA1615, VMA1630, and VMA1832 for Connecting
Tubing, Bulk Pack of 10
F-1000-325
Flexible Tubing Extension with Barbed Fitting for VMA1615, VMA1630, and VMA1832, 35.56 cm
(14 in.) Length, Bulk Pack of 20
F-1000-326
VMA Actuator Assembly Gearbox Replacement KitMS-VMAACT-701
Portable BACnet/IP to MS/TP RouterTL-BRTRP-0
Technical Specifications
Table 11: VMA1615/1626/1628/1630 Controllers
MS-VMA1615-x: 32-bit, Integrated VAV Controller/Actuator/Pressure Sensor - DPT, 3 UI and 2 BO,
24VAC, FC and SA Bus
MS-VMA1626-x: 32-bit, Integrated VAV Controller/Actuator (No Pressure Sensor - DPT); 3 UI, 3
BO, and 2 CO; 24VAC; FC and SA Bus
MS-VMA1628-x: 32-bit, Integrated VAV Controller/(No Actuator) Pressure Sensor - DPT; 3 UI, 3
BO, and 2 CO; 24VAC; FC and SA Bus
MS-VMA1630-x: 32-bit, Integrated VAV Controller/Actuator/Pressure Sensor - DPT; 3 UI, 3 BO, and
2 CO; 24VAC; FC and SA Bus
Product Code Numbers
BACnet MSTP, N2Communications
Protocol
All Model types. Some NIE models support MS/TP and N2 devices. Refer to the Network Engines
Product Bulletin (LIT-12012138) for details.
Engines
24 VAC (nominal, 20 VAC minimum/30 VAC maximum), 50/60 Hz, Power Supply Class 2 (North
America), Safety Extra-Low Voltage (SELV) (Europe)
Supply Voltage
10 VA typical, 14 VA maximum
Note: The VA rating does not include any power supplied to the peripheral devices connected to
Binary Outputs (BOs) or Configurable Outputs (COs), which can consume up to 12 VA for
each BO or CO, for a possible total consumption of an additional 60 VA (maximum).
Power Consumption
Operating: 0 to 50°C (32 to 122°F)
Storage: -40 to 70°C (-40 to 158°F)
Ambient Conditions
Inputs/Outputs: 6.3 mm (1/4 in.) Spade Lugs
FC Bus, SA Bus, and Supply Power: 4-Wire and 2-Wire Pluggable Screw Terminal Blocks
FC and SA Bus Modular Ports: RJ-12 6-Pin Modular Jacks
Terminations
DIP switch set; valid field controller device addresses 4–127
(Device addresses 0–3 and 128–255 are reserved and not valid field controller addresses.)
Controller Addressing
for BACnet MSTP
DIP switch set; valid field controller device addresses 1–255Controller Addressing
for N2
21VMA1615/1626/1628/1630 VAV Controllers Installation Instructions
