Configuration Guides—XT-9100 Configuration Guide 19
Each digital output is defined and configured by the following parameters:
Tag name (GX-9100 only)
Output type
Pulse time
When the XT is connected to a DX-9100 Controller, the following
parameter is defined in the DX-9100 for the digital output:
Source
Via the GX Tool
Select XTn (or EXP) and DOn, then select either of the On/Off or
Pulse fields. For the Pulse type, the output switches for a configurable
pulse time for each state transition of the command output.
Via the SX Tool
The output type for outputs DO1-DO8 can be selected in Item DOT1
(RI.66) for XP1 and Item DOT2 (RI.67) for XP2 as follows:
X1 = 0 On/Off Type (Maintained)
X1 = 1 Pulse Type; the output switches for a configurable pulse time
for each state transition of the command output
This parameter is set once for all pulse type outputs in the XT-9100.
Via the GX Tool
Select XTn, XTn, and Data, then enter a value in the “Digital Output Pulse
Time” field. The valid range is 1 to 250 (5 msec to 1.25 seconds pulse
time).
Via the SX Tool
The digital output pulse time can be defined in Item DOPT (RI.68) in units
of 5 msec. The default value is 200, which represents a pulse time of
1 second.
Note: All connected DO points must be configured to ensure correct
operation with the DX-9100 Controller. When a single XP-9106
(4DO) relay module is connected, select 8 DO on the GX Tool and
define outputs DO1-DO4 only.
Digital Output
Configuration
DO: Type of
Output
DO: Pulse Time
