Johnson Controls ZJ Series User Manual

5803635-YIM-A-0220
30 Johnson Controls Ducted Systems
CONDENSER FAN DATA
Quantity of fans 2 2 2 2 4
Fan diameter (Inch) 24 24 24 24 24
Type Prop Prop Prop Prop Prop
Drive type Direct Direct Direct Direct Direct
Quantity of motors 2 2 2 2 4
Motor HP each 1/3 3/4 3/4 3/4 1/3
No. speeds 1 1 1 1 1
RPM 850 1110 1110 1110 850
Total CFM 7400 8000 9000 9400 14000
BELT DRIVE EVAP FAN DATA
Quantity 1 1 1 1 1
Fan Size (Inch) 15 x 15 15 x 15 15 x 15 15 x 15 15 x 15
Type Centrifugal Centrifugal Centrifugal Centrifugal Centrifugal
Motor Sheave 1VL40 1VM50 1VL40 1VM50 1VM50 1VM50 1VM50 1VM50 1VM50 1VP56
Blower Sheave AK74 AK74 AK69 AK69 AK89 AK74 AK84 AK74 AK74 BK77
Belt A53 A54 A52 A54 A56 A54 A56 A54 A54 BX56
Motor HP each 1-1/2 2 1-1/2 3 2 3 2 3 3 5
RPM 1725 1725 1725 1725 1725 1725 1725 1725 1725 1725
Frame size 56 56 56 56 56 56 56 56 56 184T
FILTERS
Quantity - Size
4 - (24 x 20 x 2)
5,6
4 - (24 x 20 x 2)
5,6
4 - (24 x 20 x 2)
5,6
4 - (24 x 20 x 2)
5,6
4 - (24 x 20 x 2)
5,6
4 - (24 x 20 x 4)
7
4 - (24 x 20 x 4)
7
4 - (24 x 20 x 4)
7
4 - (24 x 20 x 4)
7
4 - (24 x 20 x 4)
7
1. Cooling Only Unit or Cooling Unit with Electric Heat
2. Cooling Unit with Gas Heat
3. 1
st
Stage 50% of Full Capacity.
4. ZJ078 through ZJ150 have crankcase heaters standard
5. 2 In. Throwaway, Standard, MERV (Minimum Efficiency Reporting Value) 3.
6. 2 In. Pleated, Optional, MERV 8.
7. 4 In. Pleated, Optional, MERV 13.
ZJ078-150 Physical Data (Continued)
Component
Models
ZJ078 ZJ090 ZJ102 ZJ120 ZJ150
Nominal Tonnage 6.5 7.5 8.5 10 12.5
