6
ENGLISH
Typical applications
The Viking Power 16 is a single diaphragm
DC-pump. This pump is the ideal choice for
shower drain, waste water and bilge pump
-
ing. Its compact design and flexible orien
-
tation give a very adaptable mounting and
installation in the boat.
Model number
Viking Power 16 12V 10-13350-03
Viking Power 16 24V 10-13350-04
Features
• 16 L/min (4.2 GPM) at open flow
• 15 L/min (4.0 GPM) at 0.1 bar pressure
• Compact and flexible configuration and
installation
• Quick disconnect fittings (1" or ¾" hose
and ½" BSP) straight included and 90° as
accessory
• Quiet operation
• Smooth flowing
• Self priming to 3 m (10 feet)
• Pump head can be rotated 360°
• Three alternatives to motor orientation
• Dry running without damage
• No filter required
• Ball-bearing supported transmission
• Low power consumption (30W)
• Meets ISO15083 Small Craft Bilge Pump
standard for boats up to 12 m/40 feet
Working principle
Single-chamber, self-priming diaphragm
pump. To obtain good self-prming ability
and a filter-less solution, the pump is de
-
signed with a large single diaphragm and
a long stroke. This way a lot of water is
pushed through the valves in each stroke
and any debris is flushed through.
Technical description
Body: Nylon
Valves: Nitrile
Diaphragm: Reinforced nitrile
Connection: KlickTite™ XL connectors
1" hose or ¾" hose and
½" BSP, straight included
and 90° as accessory
Fasteners: Stainless steel
Fot: Painted zink plated steel
Max. head: 3 meters (10 feet)
Max.
suction lift: 3 meters (10 feet)
Max head
& lift: 4 meters (13 feet)
Motor: 30 W at 1 m head
12/24 V DC (with built-in
thermal protection)
Fuse size: 8 A – 12V / 4 A – 24V
The pump is CE marked according to the
following standards:
• EN55014-1:2000/Radio disturbance
• EN55014-2:1997/Radio disturbance
• ISO8846: Small Craft – Electrical devices
– Protection against ignition of surround
-
ing flammable gases
• ISO8849:2003/ Small craft – Electrically
operated bilge pumps
• ISO10133: 2001/Small Craft – Electrical
systems – Extra-low voltage DC installa
-
tions
Drawing
See page 25
Pressure and Capacity data
Pressure Flow Amp. draw
Bar kPa Psi L/min USGPM 12V 24V
0 0 0 16.2 4.2 2.0 1.0
0.1 10 1.5 15.1 4.0 2.3 1.2
0.2 20 2.9 13.7 3.6 2.8 1.4
0.3 30 4.4 12.5 3.3 3.4 1.7
0.4 40 5.8 11.3 3.0 4.0 1.9
Fuse required 8 A 4 A
Viking Power 16 mounted to DC motor 12/24 V
Please follow all instructions before attempting an installation.
