Johnson C8000 User Manual

22
JOHNSON BIKE C8000 / R8000
23
JOHNSON BIKE C8000 / R8000
STEP 6
FINAL ASSEMBLY
OPTIONAL ENTERTAINMENT ACCESSORY SHOWN
ëHANDLEBAR
Mount the upper handlebars to the console mast using four screws (Z04). Tighten with
the #5 Allen Wrench (Z32).
ëCONSOLE
Remove the four mounting bolts from the back of the console. Connect the wire
harnesses and heart rate wires that come from the console mast into the plugs located
in the back of the console. Attach the console to the mast with the four bolts removed
earlier.
Z04
R
L
