JOHNSON CLASS CYCLE P8000 JOHNSON CLASS CYCLE P8000
ASSEMBLY
ASSEMBLY PARTS LIST
Use the following procedures to unpack and assemble the Class Cycle.
UNPACKING THE CYCLE
The Johnson Class Cycle is carefully inspected before it is packaged. Remove all parts from
the shipping carton and foam inserts, and verify that the following parts are included in
your shipment. After unpacking, dispose of the carton material properly.
CAUTION: This unit weights 118 lbs / 54 kg. To avoid injury to the user and the unit, be sure
to have proper assistance to remove or move the unit.
NOTE: In case any of these parts are missing from the package, please contact Johnson
Fitness or the local authorized dealers at once.
A) Main Frame Assembly
(A)
(B)
(E)
(C) (D)
B) Handlebar Set
C) Rear Foot
D) Front Foot
DESCRIPTION QUANTITY
1
1
1
1
E) Hardware Box
(including Seat × 1,
Pedal × 2, Quick Release
Lever Set × 2,
Hardware Kit × 1)
DESCRIPTION QUANTITY
1
FASTENERS & ASSEMBLY TOOLS
ASSEMBLY INSTRUCTIONS
ASSEMBLY EXPLODED DIAGRAM
Socket Head Screw (Low Head) (M8×20L)
#5 Allen Wrench (5mm)
Open Wrench (#13 / #14 / #15)
PARTS NO. DESCRIPTION QUANTITY SKETCH
Z01
Z31
Z32
4
1
1
Z01
Z01
Z01
Z01
AT2
D06
AG2
G11
G10
D14
G10
