Johnson E8000 User Manual

ASSEMBLY
PARTS NO. DESCRIPTION
QUANTITY
Z10
Z03
Z04
Z07
Z05
Z06
Z07
Z18
Z01
Z02
Z22
Z24
Z25
Z08
Z14
Z20
Z19
Z17
Socket Buttonhead Screw (M8 X 1.25p X 20mm)
Socket Buttonhead Screw (M8 X 1.25p X 80mm)
Flat Washer (Ø8.2)
Nylon Nut (M8 X 1.25p)
Bushing
Buttonhead Bolt (M8 X 1.25p X 35mm)
Nylon Nut (M8 X 1.25p)
Buttonhead Screw (M6 X 1.0p X 20mm)
Buttonhead Screw (M8 X 1.25p X 16mm)
Spring Washer (Ø8.2)
Cross Head Screw (M5 X 0.8p X 25mm)
Spring Washer (Ø8.2)
Socket Head Screw (M8 X 1.25p X 25mm)
Link Arm Cap
#5 L-type Wrench (120L)
#6 T-type Wrench (167L)
Phillips Screwdriver
Wrench (#13)
2
2
4
2
4
2
2
8
8
8
2
4
4
4
1
1
1
1
0706
JOHNSON ELLIPTICAL E8000JOHNSON ELLIPTICAL E8000
SKETCH
ASSEMBLY EXPLODED DIAGRAM
FASTENERS & ASSEMBLY TOOLS
COLOR
OF BAG
Yellow
Red
Black
Pink
Z10
N22
Z05
Z07
Z08
Z06
Z18

Johnson E8000 Specifications

General

Brand	Johnson
Model	E8000
Category	Elliptical Trainer
Language	English
