Joie i-Level - Height Adjustment for Head Support and Shoulder Harnesses; Adjusting the Backrest Angle

11 12
15
16
Height Adjustment
for Head Support and Shoulder Harnesses
see images
15
-
18
Check that shoulder harness straps
are set at the proper height. please
choose the proper pair of shoulder
harness slots according to the child’s
height.
!
The bottom of headrest must be
level with the highest point of
child’s shoulder, it is shown as
15
,
but not above the shoulder line.
16
!
If the shoulder harness straps are
not at proper height, the child
might be ejected from the
enhanced child restraint if there is
a crash.
17
Squeeze the head support
adjustment lever
17
, meanwhile pull
up or push down the head support
until it snaps into one of the 7
positions. The head support positions
are shown as
18
18
Adjust Backrest
see images
19
-
20
19
There are 3 angles for the backrest.
Please press backrest adjustment
button to heighten or lower the
backrest.
20
