7 8
Booster Assembly
4. Align the side impact shield
with the slot of lower back
support plastics mounts, and
then insert to lock.
4
5
!
Please choose whether to
install the side impact shield
according to the size of the
car.
5. Remove side impact
protection. Please refer to
6
7
see images
1
-
7
1. Squeeze the head support
adjustment latch first and
then slide in lower back
support under the fabric
cover to connect them
together.
1
!
CHECK to make sure
two pieces are securely
snapped together by
pulling on them.
2. To attach the lower back
support to the base, hook
the lower back support over
the seat bar hinge on the
base.
2
3. Rotate the lower back
support up while holding the
booster seat until it clicks
into an upright position.
3
1
3
2
4
5
7
6
To Next Page
