31
32
Important
1. DO NOT use forward facing mode before the child's weight exceeds 9kg.
2. When the child is suitable for both toddler and baby modes﹐ it is
recommended to install this child restraint in the baby mode as it is
relatively safer.
Choose the Installation Mode
Emergency
In case of emergency or accidents﹐ it is most important to have your child
taken care of with first aids and medical treatment immediately.
Parts List
Fig. 1.1 Head Support Fig. 1.11 Lock-off Device
Fig. 1.2 Seat Pad Fig. 1.12 Head Support
Fig. 1.3 Buckle Adjustment Lever
Fig. 1.4 Adjustment Adaptor Fig. 1.13 Shoulder-belt Slot
Fig. 1.5 Adjustment Webbing Fig. 1.14 Rear Cover
Fig. 1.6 Recline Adjustment Fig. 1.15 Instruction Manual Storage
Handle Compartment
Fig. 1.7 Webbing Adjuster Fig. 1.16 Base
Fig. 1.8 Crotch Strap Fig. 1.17 Body
Fig. 1.9 Shoulder Strap Fig. 1.18 Back Slot
Fig. 1.10 Small Child Insert Fig. 1.19 Seat Slot
Soft goods include Seat Pad, Shoulder Strap, Crotch Strap, Head Support and
Small Child Insert.
Please make sure there are no missing parts. Please contact the distributor
if anything is missing.
寶寶
體重
安裝模式 安裝圖示 參考年齡 座椅段位 小座墊使用說明
未滿
18
公斤
嬰兒模式
幼童模式
學童模式
未滿
4歲
第 4 段
第1-3段
第1-2段
小座墊可輔助安全
帶綁緊寶寶
並讓寶寶
背部躺平，避免
脊椎彎曲
9 -18
公斤
1 - 4 歲
拆除小座墊
15 -25
公斤
3 - 7歲
拆除小座墊
Child's
Weig ht
Installation
Mode
Figure for
Installation
Reference
Age
Seat Child insert
Position Instructions
<18kg
9 - 18 kg
15 - 25 kg
+
Baby mode
Toddler
mode
Junior mode
Small
child insert
<4 years
Small child insert
is used to
help restrain
the child tightly
and level the
child's back to
avoid cyrtosis
1 year
to
4 years
3 years
to
7 years
Position 1 -3
Position 1 -2
Position 4
Disassemble the
Small child insert
Disassemble the
Small child insert
4
3
2
2
1
1
4
3
2
2
1
1
小座墊適用於
0-6個月的寶寶
Small child insert
must be used for
children 0-6 months.
