Jonsered CS 2147 - Bar and Chain Combinations

English – 37
TECHNICAL DATA
Bar and chain combinations
The following combinations are CE approved.
Bar
Chain
Length,
inches
Pitch, inch
Max. number
of teeth on tip
sprocket
13 0,325 10T Jonsered S30
15 0,325 10T Jonsered S30
16 0,325 10T Jonsered S30
18 0,325 10T Jonsered S30
20 0,325 10T Jonsered S30
13 0,325 10T Jonsered S25
15 0,325 10T Jonsered S25
16 0,325 10T Jonsered S25
18 0,325 10T Jonsered S25
20 0,325 12T Jonsered S25
D
2
L
_
D
PITCH =
