Jonsered CS 2152 - Bar and Chain Combinations; Saw Chain Filing and File Gauges

English – 39
TECHNICAL DATA
Bar and chain combinations
The following cutting attachments are approved for the models Jonsered CS 2152, CS 2152W, CS 2152WH, CS 2152C,
CS 2153, CS 2153C, CS 2153WH and CS 2153CWH. The saw chain Jonsered H30 is designed to minimize kickback
(classified saw chain of low kickback type according to ANSI B175.1).
Saw chain filing and file gauges
Bar Chain
Length, inch Pitch, inch Gauge, mm Max. nose radius Type Length, drive links (no.)
13 0,325 1,3 10T
Jonsered H30
56
15 0,325 1,3 10T 64
16 0,325 1,3 10T 66
18 0,325 1,3 10T 72
20 0,325 1,3 10T 78
13 0,325 1,5 10T
Jonsered H25
56
15 0,325 1,5 10T 64
16 0,325 1,5 10T 66
18 0,325 1,5 10T 72
20 0,325 1,5 12T 78
