50 - English
Repair Instructions
4
Loosen the cable to the carburettor’s heating
element. See Figure 18.
Fig 18
2
Loosen the pressure hose A, the return hose B and
the tank bleeding hose C. See Figure 16.
Fig 16
3
Loosen screws F and unhook the rubber mounting
G on both sides of the air lter holder. See Figure
17.
Fig 17
Replacing the carburettor’s heating
element and thermostat
1
Remove the cylinder cover and air lter. Loosen
the thermostat cable from the air lter holder
as well as from the cabling in the front handle.
Loosen the two screws holding the thermostat’s
attachment bar and remove the thermostat. See
Figure 15.
Fig 15
