English - 27
Repair Instructions
WARNING!
Exercise care to ensure the spring
does not fly out and cause person-
al injury. Wear protective goggles.
7.4 Replacing a broken return spring
1
Loosen the screw at the centre of the starter pulley
and loosen the screws on the cassette. Remove
the starter pulley with the cassette and spring.
2
Remove the broken cassette and replace it with a
new one.
3
Tighten the screw at the centre of the starter pulley,
at a tightening torque of 2-3 Nm. Load the return
spring, see “Loading the return spring”. See also
the “Dismantling the starter” chapter.
7.5 Starter assembly
1
Position the starter against the crankcase and
tighten the screws at a tightening torque of
3-4 Nm.
