18 – English
ASSEMBLY
Fitting other guards and cutting
attachments
• Fit the trimmer guard/combination guard (A) intended for
use with the trimmer head/plastic blades. Secure the
trimmer guard/combination guard using four screws (L)
and the support plate (M) as shown.
• Fit the drive disc (B) on the output shaft.
• Turn the blade shaft until one of the holes in the drive disc
aligns with the corresponding hole in the gear housing.
• Insert the locking pin (C) in the hole to lock the shaft.
• Screw on the trimmer head/plastic blades (H) in the
opposite direction to the direction of rotation.
• To dismantle, follow the instructions in the reverse order.
Adjusting the harness and clearing
saw
Quick release
At the front is an easily accessible, quick release. Use this if
the engine catches fire or in any other emergency situation
that requires you to free yourself from the machine and
harness.
Spreading the load on your shoulders
A well-adjusted harness and machine makes work much
easier. Adjust the harness for the best working position.
Tension the side straps so that the weight is evenly distributed
across both shoulders.
Correct height
1 Forestry clearing
Adjust the support strap so that the support hook is
around 10 cm below your hip. The blade should be angled
forward a little.
2 Grass clearing
The support hook should hang around 20 cm below your
hip so that the blade is parallel to the ground.
Correct balance
1 Forestry clearing
Move the hanging ring on the machine forward or
backward. It is easier to avoid sawing into the ground if the
blade is balanced a few dm above the ground.
2 Grass clearing
Let the blade balance at a comfortable cutting height, i.e.
close to the ground.
!
WARNING! When using a clearing saw it
must always be hooked securely to the
harness. Otherwise you will be unable to
control the clearing saw safely and this can
result in injury to yourself or others. Never
use a harness with a defective quick release.
B
A
L
M
C
H
H
