Assembly Instructions
1. Set the lower handlebar in place. (A)
2. Fit the lower handle ensuring that the formed ends
are located properly in corresponding slots either
side of the lawnmower.(B)
3. Insert the plastic plugs on both sides. (C)
4. Assemble the upper handle. Note: washer between
wing nut and handle. (D)
Handlebar Stop
• THE 2 HANDLEBAR STOPS MUST BE FITTED
BEFORE USE
1. In the packaging you will find 2 stops one marked -
H- and one marked -V-.
2. To lock the handlebar in a fixed position, attach the
stops as shown in the illustration (E).
3. Place -H- on the right side and -V- on the left side.
Recoil Starter
1. Disconnect the spark plug lead.
You must release the brake by pulling the OPC lever
to the handle before pulling out the cord.
2. Pull the Operator Presence Control to release the
brake on the engine.(F)
3. Extend the pull cord fully.
4. Locate the cord in the pull cord guide positioned on
handle (G).
Filling with Oil
1. Fill the engine with oil. A bottle of the correct amount
of oil is included with the mower, SAE 30.
ADJUSTING THE CUTTING HEIGHT
1. Remove the spark plug lead before adjusting.
2. Move the axles between the notches to achieve the
desired cutting height. (H1) & (H2)
Engine Notes
Oil
1. Check oil level periodically and after every five hours
of operation.
2. Add oil as necessary to keep the level to the FULL
mark on the dipstick.
3. Use a good quality SAE 30 four stroke oil.
4. To fill with oil:- (J)
a. Remove oil filler cap.
b. Fill to the FULL mark on the dipstick.
• Change the oil after the first five hours operation and
thereafter every 25 working hours.
5. Always change the oil while the engine is warm - but not
hot - never attempt any maintenance on a hot engine.
Petrol
1. Use fresh regular grade lead free petrol.
2. NEVER USE LEADED PETROL
Using leaded petrol will make the exhaust smoke
and cause irreparable damage to engines fitted
with a catalytic converter.
3. Do not fill the fuel tank when the engine is hot.
4. Do not fill the fuel tank while smoking.
5. Do not fill the fuel tank while the engine is running.
6. To avoid introducing dirt into the fuel system, wipe all grass
and dirt from the petrol filler cap before unscrewing it.
7. It is recommended that you fill the tank through a
funnel with a filter.
8. Wipe away spillages before starting.
ENGLISH - 2
Starting and Stopping
1. Place the mower on a flat surface free from grit,
gravel, etc. Fill the tank with unleaded petrol, do not
mix with oil. (K)
2. Do not fill with petrol while the engine is running.
Any petrol spillage should be hosed away with water.
Take care that water does not enter the engine.
3. Connect the spark plug lead.
Throttle Control (if fitted)
Move the Throttle Control to the FAST ‘+’ position
before starting (L).
1. Starting the cold engine
Push primer bulb firmly 3 times before starting cold
engine. (Also, if the engine has stopped because it has
ran out of fuel, refuel engine and push primer 3 times).(M)
2. Starting the warm engine
NOTE: Priming is usually unnecessary when restarting
a warm engine. However, cool weather (55
0
F/13
0
C or
below) may require priming to be repeated.
3. Pull the Operator Presence Control all the way to the
upper handle before you start the engine. The lever
must be held in position to keep the engine running. (N)
4. Releasing the Operator Presence Control will
stop the engine within 3 seconds.
5. Start the engine by pulling the starting handle firmly
upwards. (P)
6. Stopping the engine
Release the Operator Presence Control.
Use
Due to engine lubrication limitations, the mower should
not be used on slopes in excess of 30
0.
. (Q)
Before mowing objects such as twigs, toys and stones
should be removed from the lawn. (R)
Avoid running the blade over foreign objects such as
stones, roots, etc., as it may cause engine damage.
Mow the lawn twice weekly during the most active
periods of growth.
Never cut more than 1/3 of the length of the grass,
especially during dry periods. (S)
Mow with a high cutting height setting the first time.
Examine the result and lower the mower to the desired
setting. Mow slowly or mow the grass twice if it is very
long.
Maintenance
Always remove the spark plug lead before repair,
cleaning or maintenance work.
All nuts, bolts and screws should be checked for
tightness after 5 hours use.
Check the oil.
Push the handle down to ground level when tilting the
mower for cleaning purposes. This will avoid oil and
fuel spillage.
Regularly
1. Hose down or brush off all grass, leaves, etc., from
the mower. (T)
2. Check the oil level.
Always handle the blade with care - sharp edges
could cause injury.
USE GLOVES
Renew your metal blade after 50 hours mowing or 2
years whichever is the sooner - regardless of
condition.
If the blade is cracked or damaged replace it with a
new one.
