17
KEY PART
NO. NO. DESCRIPTION
1 532 40 50-07 Plunger Asm. Lift Lvr
2 532 19 80-70 Shaft Asm. Lift
3 532 18 88-22 Pin Groove
4 812 00 00-02 E Ring #5133-62
5 819 21 16-21 Washer 21/32 x 1 x 21 Ga.
6 532 12 01-83 Bearing Nylon
7 532 10 94-13 Grip Handle Fluted
8 532 12 45-26 Button Plunger Black
11 532 13 98-65 Link Asm Lift LH
12 532 13 98-66 Link Asm Lift RH
13 532 12 46-70 Retainer Spring
15 532 17 32-88 Link Front
16 873 35 08-00 Nut Jam Hex 1/2-13 unc
17 532 17 56-89 Trunnion Blk Zinc
18 873 80 08-00 Nut Lock w/Wsh 1/2-13 unc
19 532 13 98-68 Arm Suspension Mower
20 532 19 42-09 Pin Cotter 7/16 Bowtie Lock
23 532 11 08-07 Nut Special
24 819 13 10-16 Washer 13/32 x 5/8 x 16 Ga.
25 532 12 48-74 Spring 2-1/8"
26 532 16 94-84 Retainer Clip
27 532 12 69-71 Rod Adj Lift Zinc 7.49 Wrk Lg
28 873 35 06-00 Nut Hex Jam 3/8-16 unc
29 532 13 80-57 Knob Inf 3/8-16 unc Blk w/Sym
30 532 15 02-33 Trunnion Infin Height
31 532 16 98-65 Bearing, Pvt. Lift.
32 873 54 06-00 Nut Crownlock 3/8-24
36 532 15 50-97 Pointer Height Indicator
37 532 12 39-35 Plug Hole Blk 1.485/1.515 Dia
38 817 06 05-16 Screw 5/16-18 x 1
40 819 11 24-10 Washer 11/32 x 1-1/2 x 10 Ga.
41 532 12 39-34 Scale Ind Height Blk
49 532 40 91-49 Nut hex Flange 375-16
50 532 11 04-52 Nut Push Phos & Oil
NOTE: All component dimensions given in U.S. inches
1 inch = 25.4 mm
TRACTOR - - MODEL NO. LT2113CM (96061022405), PRODUCT NO. 960 61 02-24
MOWER LIFT
45
To Next Page
