JOSAM laser AM
Measuring system
5
Measuring equipment
Trailer tow bar adapter AM48 A.
Attaches in the towing eyelet for gauge extensions
and measuring scales.
Adapter for kingpin AM69.
Attaches to kingpin for hanging the frame gauge.
Magnet bracket for frame gauge AM172.
Attaches on sides of frame for hanging frame
gauges.
Magnet bracket for frame AM1227-1 and 2.
For hanging frame gauges on vehicles with short
overhang.
4
6
Table of Contents
Introduction
2
Table of Contents
3
Measuring Equipment
4
Preparations before Measuring
10
Checking of Frame Gauge
10
Hanging the Frame Gauges
18
The Test Report Sheet
23
Measurement of Rigid Axles
26
Toe-In/Toe-Out
27
Measurement of Camber
36
Measurement of Front Axles
40
Measurement of out of Square Front Axle
44
Measurement of Camber
45
Measurement of Caster
47
Measurement of KPI
51
Measurement of Toe-Out on Turn (TOOT)
54
Measurement of Maximum Turn
55
