JOSAM laser AM
Measuring system
4
Measuring equipment
Frame gauge with hangers as well as gauge
extensions with sight pins.
NOTE! The hangers are to be correctly placed with
the straight side or cut side on the outside.
The frame gauge with stepless adjustable
attachment for the hangers.
Gauge extension with bubble for checking the
adjustment of horizontal for the frame gauges.
Measuring scale AM34 A.
Attach the gauge extension sight pin.
Sliding scale AM84 A.
Sliding scale attached to the measuring scale.
