JOTRON electronics a.s.
December, 99
Page 9
1. TECHNICAL DATA
1.1. General data
Frequency range: 118 - 136.975 MHz
Frequency stability: 10 ppm
Channel spacing: 25 kHz
Presetable channels: 8 channels
Modulation: A3 300 to 3000 Hz
Power supply: AC: 115 / 230 V ± 10 %
DC: 24 - 32 V, floating ground.
Power output will be reduced when power supply is
below 26V.
Power consumption: Less than 75 VA at 10W output, 95% modulation.
Environmental conditions :
Operating temperature: 0 to + 55
ª
C
Humidity: 90% at 40
ª
C without moist.
Shock: (Transport)
IEC-721-3-2, Class 2M3
Vibration: (Transport)
IEC-68-2-32, Class 2M3
IEC-68-2-6
Dimension: 19” standard rack.
405mm (W) * 250mm (D) * 88 mm (H)
Weight: 6,5 kg
