Jøtul F 200 User Manual

3
ENGLISH
1.0 Relationship to the
authorities
Installation of a fi replace must be according to local codes and
regulations in each country.
All local regulations, including those which refer to national
and European standards, must be observed when installing
the product.
The installation can only be put into use after it has been
checked by a qualifi ed inspector. Contact your local building
authorities before installing a new fi replace.
A product approval plate of heat-resistant material is to
be found in the ash pan. This contains information about
identifi cation and documentation for the product.
2.0 Technical data
Materiale Cast iron
Finish Black paint
Fuel Wood
Max, Log length 37 cm
Recommended log length 20-30 cm
Flue outlet Top
Flue pipe dimension Ø 150 mm
Outside air connection Alu. fl ex - Ø 80 mm
Approx. weight for
Jøtul F 200 IT/F 205 IT
ca 138 kg
Optional extras External air supply cover,
External air kit, short legs
Dimensions, distances See fi g. 1
Technical data in acc. with EN 13240 / NS 3058
Nominal heat output 6,5 kW
Flue gas volume 5,1 g/s
Chimney draught, EN 13240 12 Pa
Recommended negative pressure in
smoke outlet
16-18 Pa
Effi ciency 85,7%@6,5 kW
CO emissions (13% O
2
) 0,05 %
CO emissions (13% O
2
) 596 mg / Nm
3
NOx (13% O
2
) 106 mg / Nm
3
OGC (13 % O
2
) 43 mg C /Nm
3
Air consumption 4,2 liter/sec.
Chimney temperature, EN 13240 201
0
C
Dust (13% O
2
) 12 mg/Nm
3
Particle emission NS 3059 2,44 g/kg
Fuel consumption 1,5 kg/h
Max. kindling amount 2,2 kg
Nominal kindling amount 1,5 kg
Operation Intermittent*
*Intermittent combustion in this context means normal use of
the fi replace, i.e. fuel is added as soon as the fuel has burnt
down to a suitable amount of embers.
Register your fi replace at jotul.com for a
25-year warranty.
les combustibles recommandés.
Respectez les consignes d'utilisation. Utilisez uniquement
Verwenden Sie nur empfohlenen Brennstoen.
Montage- und Bedienungsanleitung beachten.
Follow user`s instructions. Use only recommended fuels.
standard
Certicate/
The appliance can be used in a shared ue.
Minimum distance to adjacent combustible materials:
Emission of CO in combustion products
Lot no: Y-xxxx, Year: 200x
Manufacturer:
N-1602 Fredrikstad
Norway
Jøtul AS
POB 1441
Sweden
EUR Intermittent
Nominal heat output
Norway
Country
Operational type
Fuel type
Operation range
Eciency
Klasse II
Classication
Standard
Flue gas temperature
Room heater red by solid fuel
Product:
Jøtul
SP Sveriges Provnings- och
221546
Forskningsinstitut AB
SP Swedish National
Testing and Research
Institute
:
Approved by
:
:
:
:
:
:
:
Minimum distance to adjacent combustible materials:
OGC
SP
EN
Lot no. Pin.
On all our products there is a label
indicating the serial number and
year. Write this number in the
place indicated in the installation
instructions.
Always quote this serial number
when contacting your retailer or
Jøtul.
UK - Installation and
operating instructions
Table of contents
1.0 Relationship to the authorities 3
2.0 Technical data 3
3.0 Safety 4
4.0 Installation 9
5.0 Daily use 13
6.0 Maintenance 15
7.0 Service 16
8.0 Operational problems -
troubleshooting 18
9.0 Optional equipment 18
10.0 Recycling 18
11.0 Guarantee terms 18
