79
ENGLISH
Fig. 1
Jøtul F 205
F 205 Short legs
Hole in the oor for external air Ø80
Min. distance to ceiling and furniture
Combustible wall
900297-P00
Firewall (See chapter 3.3 in the manual)
Min. measurments oor plate
X/Y = According to national laws and regulations
Semi isolated ue pipe/Cover ue pipe
all the way down towards the product
Min. distance to combustible wall
