Jøtul GF 3 CF User Manual

13
Table of contents
Installation signature form ..................................................... 12
Annual service signature form ............................................... 12
Relationship to the authorities
Technical data of Jøtul GF 3 CF .............................................. 13
Optional equipment ................................................................. 14
Safety precautions .....................................................................14
Installation guide for qualified personnel
Firewall requirement ................................................................ 14
Requirements for the floor plate .......................................... 15
Position of theappliance .......................................................... 15
Assembly prior to installation ................................................ 15
The vent system.......................................................................... 15
Closure plate installation ......................................................... 15
Gas installation
Testing gas pressure ..................................................................16
Testing the flue system ............................................................16
Regulating the pilot flame ...................................................... 17
Annual service ............................................................................. 17
Electrical connections................................................................ 17
Operating instructions
Lighting instructions ................................................................. 17
Adjusting the temperature ......................................................18
Turning off the fireplace...........................................................18
The combustion principle for gas ......................................... 18
Required heat during combustion ....................................... 18
Generation of sparks at the pilot head ............................... 18
Trouble-shooting
When no spark is generated at the pilot head.................. 18
Fuel gas
When there is no gas flow at the pilot head .....................19
When the pilot goes out, problems with the
gas supply .................................................................................... 19
Thermocouple ............................................................................. 19
When the pilot goes out: ........................................................ 20
Problems with the flame pattern......................................... 20
Maintenance
External maintenance .............................................................. 20
Check list ....................................................................................... 21
Technical drawings ............................................................. 56-57
Read all these instructions before installation &
use of this appliance.
Relationship to the
authorities
This product, the Jøtul GF 3 CF, may only be used with Natural
Gas G20 or be converted for the use of Natural Gas G25,
LPG.
This product is in accordance with Regulations for Gas
Appliances and Equipment, established by the European
Standard CEN EN 613 1998.
Assembly and installation must be performed by a qualified
person in accordance with the instructions for assembly,
installation and use enclosed with the product and other
national and local rules in force. In the UK this includes the
Gas Safety (Installation & use) Regulations 1998. The
installation may only be operated after it has been
inspected by a qualified person and a certificate of
completion has been issued.
Technical data of Jøtul GF 3 CF
Material: Cast iron/steel
Finish: Enamel or black paint
Flue outlet: Top/Rear
Flue pipe: 125 mm dia.
Weight: Product approx. 63 kg
Coal set approx. 6,3 kg
Log set approx. 5,3 kg.
ID no.: 048BM 0036
Appliance category:
Logs only:
Country Category Pressure
Natural Gas/LPG G30/
G31
DK + SE + FI + NO : II
2H3B/P
20/30 mbar
AT : I
2H
20 mbar
LU + DE : I
2E
20 mbar
NL : II
2L3B/P
25/30 mbar
IT+GB+ES+PT+
IE+CH+GR : II
2H3+
20/28-37 mbar
FR/BE : II
2E+3E
20-25/28-37 mbar
Coals only:
Country Category Pressure
Natural Gas/LPG G31
AT+DK+FI+SE I
2H
20 mbar
FR+BE II
2E+3P
20/25, 28-30/37 mbar
ES+CH+GB+IE+IT+PT II
2H3p
20 / 28, 37 mbar
LU+DE I
2E
20 mbar
NL: II
2L3P
25, 30/50 mbar
ENGLISH
