2. SPECIFICATION
MEASURING RANGES
Capacitance 25 pF - 100 mF
Resistance 0,01 Ω - 50 MΩ
Inductance 0,01 mH - 20 H
Battery 0,1 V - 4,5 V
Z-diode breakdown voltage 0,01 V - 30 V
Z-diode 0,01 V - 4,5 V
Diode U
F
< 4,5 V
Thyristor / Triac I
GT
< 6 mA
MAIN FEATURES
Measurable components
Resistor, capacitor,
inductor, thyristor, triac,
(double) diode, Z-diode, field
eect transistor,
bipolar transistor,
infrared decoder
Supported IR-protocol NEC
Display type 1.8″ TFT LCD (160 x 128 p)
Special features
Automatic calibration,
One key operation
Built-in battery
Lithium Ion rechargeable,
3,7 V, about 300 mAh
Size 90 x 70 x 27 mm
This LCR meter oers a wide range of functions at a low price. The LCR
meter can measure capacitance, resistance, and inductance among
other things. In addition, it can automatically recognize components, for
example, it can distinguish between dierent types of transistors, such as
NPN or PNP transistors. The device is particularly easy to operate, as all
measurements are started at the touch of a single button.
Thanks to the integrated about 300 mAh battery, measurements can also
be carried out on the road. The battery is charged with the help of a 5V
power supply unit (available separately) and the enclosed micro-USB
cable. In addition, this measuring device can decode infrared signals and
show them as a waveform on the display.
The LCR-T7 is not a professional measurement instrument and due to the
large number of dierent components on the market, it cannot be
guaranteed that all components will be correctly detected.
