1 20003964 防护板支架
protection apron bracket
1
2 10005016 垫圈 Washer 3
3 10001413 防护板螺钉垫片 protection apron Screw washer 1
4 10003021 螺母 nut 2
5 10003235 垫圈 Washer 1
6 10005271 螺钉 Screw(M5×12) 2
7 10001607 防护板
protection apron
1
8 10007096 螺钉(M5×10) Screw(M5×10) 11
9 20003397 折板
Zone Plate
1
10 20003973 后盖板喷漆
back cover board painting
1
11 20003398 后盖前板 back cover(front) board 1
12 20003409 后盖板 back cover board 1
13 20003974 后防护罩喷漆 back shield 1
14 10005124 油塞
oil dam
1
15 10005501 油塞
oil dam
1
16 10005152 皮带右防护罩
Force Shield(right)
1
17 10005269 皮带左防护罩
Force Shield(left)
1
18 10005303 M5×40螺钉 Screw(M5×40) 6
19 10005321 皮带防护下罩 Force Shield(down) 1
20 10005003 螺钉 Screw(M5×8) 5
21 20003399 挑线杆护罩 Shield 1
22 20003972 电磁铁防护罩喷漆 Shield painting 1
23 10005107 螺钉 Screw(M4×6) 2
24 10005274 面板
Panel
1
25 10005468 面板装饰牌 panel brand 1
26 10004967 螺钉 Screw(M5×35) 1
27 10005430 螺钉 Screw(M5×25) 1
28 10001658 面板
Panel
1
29 10005042 油绳 Wick 1
30 10001606 面板过线板毡
Panel felt
1
31 10004974 螺钉 Screw(M6×10) 2
32 10005426 支脚 bracket 1
33 10005008 支板 trestle board 1
34 10005122 螺钉 Screw(M4×30) 2
35 10005539 螺钉 Screw(M5×6) 1
36 10005187 弹簧 spring 1
37 10005296 机头油盘组件 Head Oil Reservoir 1
38 10005349 板 Board 1
39 10005425 弹簧垫 Spring Washer 1
40 10005016 垫圈 Washer 1
41 10005322 螺钉 Screw(M5×10) 1
42 10005363 油盘油毡垫 Oil Reservoir Gasket 6
43 10008323 螺钉 Screw(ST4.2×20) 6
机身部件
Housing sections
序号
No.
件号
Pars No.
名称 Description
数量
Number
To Next Page
