1 10005487 挡圈 Collar 2
2 10005399 宛形曲柄
crank
1
3 10005073 宛形曲柄轴承
crank bearing
1
4 10005372 螺钉 Screw(M6×16) 1
5 10005194 输送主轴挡圈垫片 washer 1
6 10005043 万向联接座
base frame
1
7 10012752 螺钉 Screw(M4×10) 3
8 10010953 螺钉 Screw(M5×10) 1
9 10005212 万向联接头
Union
1
10 10005343 油毡垫片 Washer 4
11 10005366 螺钉 Screw(M4×12) 2
12 10005179 球连杆组件
Ball Connecting Rod
2
13 10024475 调整垫圈 Adjustable washer 2
14 10005286 滚轮联接轴轴承 Roller wheel coupling spindle bearing 2
15 10005506 轴承座 bearing seat 2
16 10005465 轴承座垫片 bearing seat washer 4
17 10005377 轴承座挡圈 bearing seat collar 4
18 10005048 滚轮压脚组件 idler wheel foot asm. 1
19 10005301 滚轮联接轴
Roller wheel coupling spindle
1
NOTE 注记 #1…FOR 9610 9610用
#2…FOR 9620 9620用
机头零件
Needle head parts
序号
No.
件号
Pars No.
名称 Description
数量
Number
-4-
