Magnetic limit switch - The installation site of magnetic limit switch is shown in Figure 10:
GateGate
MagnetsMagnets
MagneticMagnetic limitlimit switchswitch stopstop blockblock
GearGear rackrack
OutputOutput geargear
20mm
Figure 10
The installation of magnetic limit switch block is shown in Figure 11:
M6×18M6×18 M6×18M6×18
Left side mounting
Right side mounting
Figure 11
Note: The default setting is right side mounting. (According to actual situation, please refer to the
Note of section 4.3.5.1 and 4.3.5.2 Adjustment and operation to adjust.)
