JP Selecta UV 2005 - Technical Specifications

MANUAL DE INSTRUCCIONES CODIGO 80243 REV A Enero /11 (Sujetas a modicaciones sin previo aviso) Pag.: 54
J.P. SELECTA s.a. Ctra. NII Km 585.1 Abrera 08630 (Barcelona) España Tel 34 93 770 08 77 Fax 34 93 770 23 62
e-mail: selecta@jpselecta.es - website: http://www.jpselecta.es
10 Technical Specications
Mains voltage: 230V - 110V 50/60Hz (See features
label)
Electric power: 110W (See features label)
Maximum intensity: 0.4 A
Fuses: 3.15 A fast. dimensions: 20x5 mm
Network connection cable: Phase, Neutral, Earth (section 1mm
2
)
Weight (Net): 14 Kg
Dimensions: Depth x Width x Height 370 x 470 x 180 mm
Model UV 2005
Wavelength range 190-1100nm
Spectral wavelength 2nm
Optical system one beam with 1200 lines/mm net
Wavelength accuracy ± 0,5nm
Wavelength reproducibility 0,3nm
Wavelength resolution ±0,1nm
Accuracy ±0,3%
Repeatability ±0,2%
Reading range from -0,3 to 3A,T 0-200%
Diffuse light 0,05% @ 220nm
Stability ±0,002 A / h @ 500nm
LCD screen (128x64 dots)
Membrane keyboard 22 keys
Reading modes transmission - absorption - concentration
Photodetector Silicon photodiode
Sample compartment Standard cuvettes 10 mm.
Cuvettes capacity 100 mm.
Light source Tungsten and deuterium lamps
Ports outlet USB- parallel port (printer)
Sound level Less than 60 dBA
Environmental conditions: Inner use
Altitude up to 2000m
Temperature between 5ºC & 40ºC.
Maximum relative humidity 80% for tem-
peratures up to 31ºC, linearly decreasing
till 50% relative humidity to 40ºC
Overvoltage Category II
Pollution rank 2
