3.8 Applied Operations
y
y y
Setting display brilliance (Brilliance Setting)
Procedures 1 Press the [RADAR MENU] key twice.
2 Open the Brilliance Setting menu by performing the following menu
operation.
5. Sub Menu
→ 2. Brilliance Setting
3
Setting brilliance of each element
• Specify the brilliance for the element.
• Level4 indicates maximum brilliance and Level1 indicates minimum brilliance.
• The brilliance for the following elements can be specified.
RADAR Video : The brilliance of the radar video is selected.
RADAR Trails : The brilliance of the radar trails is selected.
Target Symbol : The brilliance of the target symbol is selected.
Range Rings : The brilliance of the range rings is selected.
EBL / VRM / PI : The brilliance of the EBL / VRM / PI is selected.
Character : The brilliance of the character and bearing scale is
selected.
Own Symbol / HL / Vector : The brilliance of the own ship symbol, heading line,
and own ship vector is selected.
Keyboard : The brilliance of the operation panel is selected.
Note: Those selected brilliance can be saved for each Day / Night mode.
Setting radar video brilliance (VID)
The brilliance of the video of the display is adjusted.
Procedures 1 Put the cursor on radar video brilliance switching VID (brilliance /
Alarm ③ on page 2-28), and press the [ENT] key to adjust the radar
video brilliance to obtain the best-to-view video.
The brilliance of the radar video can be adjusted on four stages without opening the
Brilliance Setting menu.
Adjust the radar display to obtain the best-to-view video.
3-88
