7.2 Settings
yyy
yyyy
3. Set the baud rate of the port to be set.
Selection value
1. COMPASS : 4800(NMEA)/9600(NSK)/38400(Fast NMEA) bps
2. NAV1 : 1200/4800/9600/38400 bps
3. NAV2 : 1200/4800/9600/38400 bps
4. GPS : 1200/4800/9600/38400 bps
5. NMEA : 1200/4800/9600/38400/115200 bps
The bold values are factory-set.
The COMPASS port is a receive-only port that is dedicated to COMPASS signals.
[II] Reception Port Setting (RX Port)
Set the numbers of ports for receiving signals from sensors.
There are two methods for receiving signals: specifying a port for each sensor, or using the automatic
recognition function without specifying ports.
Procedures 1. Open the Serviceman Menu.
2. Open the RX Port menu by performing the following menu operation.
2. Installation Menu
→ 5. COM Port Setting
→ 2. RX Port
7
3. Set a port for each sensor.
Settable sensor signals
GPS, DLOG, Alarm, Depth, Temperature, Wind, Current, ROT, RSA
Selectable ports
When the automatic recognition function is used: AUTO
When ports are specified: NAV1, NAV2, GPS, and NMEA
7-12
