JRC JMA-610 User Manual

2-1
120
150
180
240
210
330
000
0
6
0
0
9
0
2
7
0
3
0
0
8
12.3m
030
300 200 100 100 200 3000
90 60 30 0 30 60
90
Fig 2.1 DISPLAY & READOUTS
Rate of Turn Indicator
Auto Pilot Indicator
Rudder Indicator
Depth or SOG Display
Depth or SOG Numeric Display
AIS Information (while push)
Range Marker Interval
Range Scale
Sea Volume Position
Rain Volume Position
Gain Volume Position
Tune Indicator
Auto Tuning
Transmit/Standby Indicator
TX Pulse Width
Center Position Select
Bearing Mode Indicator
Trail Display Time
Radar Trails mode
Screen Brilliance
Interference Rejector Switch
Display Color Mode
Target Expansion Level
(strong)
True or Relative
EBL1/2 Bearing
Menu
Own Ship’s Data
Menu Select
Cursor Position
(Azimuth, Range)
VRM 1/2 Range
P-LINE 1/2 Range
ALARM
The alarm window appears over
the P-LINE data.
Screen Capture Mode
Screen Capture
Heading Line Off
(while push)
Range Ring ON/OFF
Menu Select
GPS
Own Ship’s Data
