JRC JMA-610 User Manual

2-19
11 【DOCKING/AIS/GPS】
Select informations from Docking / GPS / AIS / OWN SHIP / OFF.
12 13 【EBL】
Refer to Section 3.5.2.
16 17 【VRM】
Refer to Section 3.5.3.
18 【HL OFF】
With the cursor positioned on the box, pressing and holding
the [ENTER] key will remove the HEADING LINE from the display.
When the key is released, the line is showed again.
19 【RANGE RINGS】
A click on the box selects between RANGE RINGS ON and OFF.
20 【SCREEN CAPTURE】
Click icon ,the screen image is downloaded to memory card.
21 【OWN SHIP INFORMATION】
Select informations from Docking / GPS / AIS / OWN SHIP / OFF.
22 【VECTORS】
A click on the box will cycle the vector time as follows.
Pressing and holding down the [ENTER] key on the box
over 2 seconds will set the VECTOR OFF.
23 【TRIP COUNTER】
Pressing and holding down the [ENTR] key on the box
will clear the TRIP COUNTER.
24 【TUNE】
Pressing the [ENTER] key on the box, you can adjust TUNE with
[TRACK BALL]. If you want to adjust TUNE with [TUNE] knob, press
[TUNE] knob on keyboard.
25 【GAIN LEVEL】
Pressing the [ENTER] key on the box, you can adjust GAIN with
[TRACK BALL]. If you want to adjust GAIN with [GAIN] knob, press
[GAIN] knob on keyboard.
