JRC JMA-7132-SA - Jma-9123-7 Xa;9 Xa

Cross Reference
iii
JMA-9123-7XA/9XA
Tab l e1- 1 ： JMA-9100 SERIES RADAR LIST OF COMPOSITION (Self-Standing TYPE)
Tab l e1- 2 ： JMA-9100 SERIES RADAR LIST OF COMPOSITION (Desktop TYPE)
Scanner Unit: NKE-1129
Table1-7： JMA-9123-7XA/JMA-9123-9XA SCANNER and TRANSMITTER-RECEIVER
UNIT
2.1.2 2695110056
2.2.4 NKE-1129 type scanner
2.4 PRECAUTIONS
Transmiter Receiver Unit: NTG-3225
2.3.1 NTG-3225 type transmitter receiver
Display Unit (self standing): NCD-4990
Table1-11： NCD-4990/NCD-4990T DISPLAY UNIT
3.1 INSTALLATION OF DISPLAY UNIT
3.3.1 Connections with NKE-1125,NTG-3225,NKE-1130,NTG-3230
OPTION Interswitch Unit: NQE-3141-2/4A/8A
5.1 INSTALLATION OF INTERSWITCH UNIT
Power Control Unit: NQE-3167
5.2.2 Connections to NKE-1125, NTG-3225, NKE-1130, and NTG-
3230
5.2.5 Connection to display unit
VDR I/F Kit: CQD-1891
5.3 INSTALLATION OF VDR
