JRC JMA-7133-SA - Connections with NKE-2103,NKE-2254

3－22
JMA-9100/7100 Installation Manual > 3.INSTALLATION OF DISPLAY UNIT > 3.3 CONNECTIONS WITH SCANNER AND
TRANSCEIVER
3.3.2 Connections with NKE-2103,NKE-2254
Connect the device to TB4101(ANT) of terminal board circuit CQD-2097 located
in the display unit (radar process unit).
In the case of a self-standing display unit, connect the device to terminal block
TB522 of AC/DC converter NBA-5135 in the display unit. In the case of a
desktop display unit, connect the device to terminal block TB401 in the
processing unit. See Section 3.2 INSTALLATION OF AC-DC CONVERTER
NBA-5135.
[Supplementation] When the device is used together with power control unit
NQE-3167, the connection of NBA-5135 is not required. In this case, execute
wiring by referring to Section 5.2.8 Inter-board connection diagram of power
control unit
For the procedure for processing the equipment cable terminal, see Section 2.1.4
Cable end processing method.
