3－62
JMA-9100 Instruction Manual > 3.BASIC OPERATION > 3.6 DISPLAY USER MAP
5) Left-click the button.
The list of navigation data saved in the system will be displayed.
6) Left-click the button for the file to be loaded.
Confirmation Window will appear.
7) Left-click the button.
The selected navigation data will be loaded and displayed on the radar display.
3.6.5.2 Discarding navigation data (Unload User Map)
Procedures
1) Open the File Operations menu by performing the following
menu operation.
→
2) Left-click the button.
Unload Confirmation Window will appear.
3) Left-click the button.
The saved navigation data will be discarded.
3.6.5.3 Storing navigation data (Save User Map)
Navigation data can be saved when navigation equipment is connected, or the own ship
position on the user map is entered in the manual mode.
Procedures
1) Insert a flash memory card into the card slot.
Flash memory card (option) is necessary.
3. Load
1. Yes
U.Map
7. File Operation
4. Unload
1. Yes
To Next Page
