7－8
JMA-9100 Instruction Manual > 7.SETTINGS FOR SYSTEM OPERATION > 7.1 SETTINGS AT INSTALLATION
3) Perform the following menu open procedure to open the Range
Adjustment menu.
→
For inputs to the value input screen, refer to Section 3.3.4.3 "Increasing or decreasing a
numeric value".
4) Adjust the range adjustment value by operating the /
button so that the target measured in step 1) falls in the correct
range.
5) Left-click the button to determine the value.
7.1.6 Navigator Setting (Device)
Determine whether to connect navigators to the radar equipment.
Only the navigators set to ON here can be used.
Procedures
1) Open the Serviceman Menu.
2) Perform the following menu open procedure to open the Device
Installation menu.
→
→
3) Select for navigators connected to the radar equipment,
and for navigators not connected.
Gyro：
Gyro (via GYRO I/F)
Compass：
Compass (Compliant with IEC61162)
GPS Compass：
GPS Compass (JRC)
LOG：
Log (via GYRO I/F)
2AXW：
2-axis log (Speed over water: Compliant with IEC61162)
2AXG：
2-axis log (Speed over ground: Compliant with IEC61162)
GPS：
GPS (Compliant with IEC61162)
1. Adjust Menu
3. Range Adjustment
＋
－
ENT
2. Installation Menu
9. Next
3. Device Installation
On
Off
To Next Page
