JMA-9100 Instruction Manual > 11.SPECIFICATION > 11.8 SCANNER UNIT (NKE-1139)
11.8 SCANNER UNIT (NKE-1139)
SCANNER UNIT NKE-1139
Dimension Height 791 x Swing Circle 4000 (mm)
Mass Approx.150kg
Polarization Horizontal
Directional Characteristics Horizontal beam width
Vertical beam width
Side lobe Level
: 1.9°
: 25°
: below -26dB (within +/-10°)
: below -30dB (outside +/-10°)
Revolution Approx.24rpm
Power Supply for Motor
AC100 - 115V、50/60Hz、1φ or
AC220 - 240V、50/60Hz、1φ
Maximum Wind Velocity 51.5m/s (100knots)
