11 －18
JMA-9100 Instruction Manual > 11.SPECIFICATION > 11.17 DISPLAY UNIT (NCD-4990)
Receivable Signal
ii
Receive capability
Port:
NAV1/NAV2/LOG/ALM/AIS/HDG at TB4501
COM DSub-9pin
Navigation equipment
IEC61162-1/2
Longitude/Latitude GGA>RMC>RMA>GNS>GLL
Waypoint RMB>BWC(BWR)
COG/SOG
RMC＞RMA＞VTG
SPEED VBW
Day/Time information
ZDA
Alarm acknowledge
ACK
Rate of Turn ROT
Rudder RSA
Bearing signal GYRO-SYNC 360x, 180x, 90x, 36x(GYRO I/F)
GYRO-STEP 360x, 180x, 90x, 36x(GYRO I/F)
IEC61162-2 38400bps
THS>HDT over 40Hz
(HDG port at terminal board TB4501)
IEC61162-1
iii
HDT>HDG>HDM>VHW
(HDG port at terminal board TB4501)
Speed signal LOG-SYNC 360x, 180x, 90x, 30x(GYRO I/F)
LOG-PULSE 800, 400, 200, 100(GYRO I/F)
External event mark
Contact input (EVENT port at terminal board TB4601)
Radar buoy Negative input (RBVD port at terminal board TB4401)
Depth IEC61162-1/JRC DPT>DBS>DBT>DBK,
JRC format
Water temperature
IEC61162-1/JRC MTW, JRC format
Tendency IEC61162-1/JRC CUR, JRC format
Wind IEC61162-1 MWV>MWD
AIS IEC61162-2 VDM,VDO (AIS port at terminal
board TB4601 )
Acknowledge
Contact input (SYSACK, ARPAACK, PWRACK port
at terminal board TB4601)
Sendable Signal
Slave video Radar video: TIY, VD, BP(2048p), BZ
(Terminal board TB4401)
Send capability
Port
NAV1/NAV2/ALM/ARPA/JARPA port at TB4501
MNT port at TB4601
COM at DSub-9pin
Navigation information
IEC61162-1/2
Radar system data RSD
Own ship data OSD
Tracking target data TTM,TLL,TTD,TLB,JRC-ARPA
AIS target data TTM,TLL,TTD,TLB
Alarm ALR
Auto pilot APB
Bearing of destination
BOD
Latitude/Longitude data
GGA,GLL,RMC
Waypoint RMB,BWC
COG/SOG VTG
Cross track error
XTE
